Fully Automatic Water Bottling Plant

The machine is a full-automatic multiple-function washing, filling and capping unit. It is used in washing. filling and sealing all kinds of non-air drinks such as fruit juice, oil & vinegar, wine, fruit wine, mineral water and pure water.

Chat Now

Product Details

Product Application

Automatic PET Bottle Water Filling Machine

Model: ADL-883(8washing heads, 8 filling heads, 3 capping heads)

Production capacity: 2000BPH for 500ml

Function Description:

The machine is a full-automatic multiple-function washing, filling and capping unit. It is used in washing. filling and sealing all kinds of non-air drinks such as fruit juice, oil & vinegar, wine, fruit wine, mineral water and pure water. The line has features of unique design, new style, complete functions, multi-purpose, convenient in operation, beautiful construction, high automatization. It is the best filling equipment in China.

SPECIFICATION DETAILS:

Head of Washing, Filling, Capping	8, 8, 3
Production Capacity	1000-2600BPH
Bottle Size	Diameter=50~108mm, H=170~340mm, 330~2.25l
Spraying Pressure	2~3 Kg/cm2
Motor Power	Main motor: 1.5KW
Power of Outer Vacuum Pump	0.75kw
Machine Size	2,100 x 1,400 x 2,500 mm
N.W.	2500 Kg
Body Material	SUS304 stainless steel
Inverter & PLC	Japan Mitsubishi
Air Valve	Taiwan AirTac
Capping Technique	Italy AROL
Heads of Washing & Filling	Ozone-resisting material
Filling Valve	304L stainless steel
Washing Pressure	0.2~0.25MPa
Bottle Clip & Fill	Bayonet style
Sealing Technique	Italy AROL sealing technique, revolve lids with magnetic force which down the wastage rate greatly.

Automatic shrink wrap packing machine

In the packaging machinery industry, the film wrapping machine is the abbreviation of the wrapping film packaging machine, sometimes called the winding machine and the wrapping machine.
Function: It is suitable for the packaging requirements of cargo storage, transportation and mechanical loading and unloading operations. Widely use the packaging cost of products such as foreign trade export, food and beverage, irrigation, paper making, dyes, plastic chemicals, glass ceramics, machine S electric castings, etc., improve production efficiency, and prevent damage of goods during handling, and play Dust, moisture and cleaning.
