Automatic Water Bottling Plant
Product Details
Product Application
The PET bottle water filling machine adapts to wide bottle type, wide range of dose adjustment, all computer control, touch color screen operation, convenient, fast and accurate, CNC adjustment is very convenient, all operation is realized automatically, the machine has stable performance, reliable work, failure rate Low, high technology content, suitable for filling soy sauce, vinegar, pharmaceutical liquid filling, is an ideal choice for liquid filling automation.
Parameter of automatic 3 in 1 water filling machine
Model | CK-DGP18 | CK-DGP24 |
Filling Bottle | PET bottles, glass bottles, etc. | PET bottles, glass bottles, etc. |
Filling Range | 350-1500 | 350-2000 |
Bottle Size | 60-96 | 60-112 |
Filling Speed | 8000bottles / hour | 20000bottles / hour |
Number of Filling Valves | 18 | 24 |
Voltage | 380V/50HZ | 380V/50HZ |
Power | 2.5KW | 7.5kw |
Dimensions(mm) | 2480*1980*2600 | 2850*2450*2600 |
Gross Weight(KG) | 4000 | 6000 |
Filling Accuracy | ≤±1% | ≤±1% |
Application of PET bottle water filling machine
Automatic 3 in 1 water filling machine is mainly used for bottled water, carbonated beverages, lotion, care solution, oral liquid, disinfectant, eye wash, nutrient solution, injection, pesticide, medicine, perfume, edible oil, lubricating oil and special industry liquid.
The PET bottle water filling machine is a perfect combination of the bottle washer, pressure filling machine and capping machine. It is a high-performance automated liquid packaging equipment. The empty bottle is conveyed to the rinsing machine through the wind conveying system, and after being turned over, the inside is cleaned by the nozzle. After the control, the high-speed and high-quality filling is carried out, and finally the sealing is safe and reliable.
